SPECIFICATIONS

• Motor: 5 HP, 220V, single-phase, 18A
• Table size: 39-1/4" x 31-1/2"
• Table counterbore: 5-3/4" dia. x 5/8" deep
• Floor-to-table height: 35-1/4"
• Spindle travel: 4"
• Spindle sizes: 3/4", 1-1/4"
• Spindle lengths: 3-7/8", 5-7/8"
• Spindle openings: 2-1/2", 4-1/8", 5-1/4", 7"
• Maximum cutter height: 5"
• Maximum cutter diameter: 7"
• Spindle speeds: 5000, 7000, 10,000 RPM
• Overall size: 39-1/2" L x 35-1/2" W x 50-1/2" H
• Approximate shipping weight: 812 lbs.

FEATURES

• Dual 4" dust ports
• DRO for height positioning
• 4-3/4" aluminum fence with featherboard attachments
• Rack-and-pinion fence adjustment
• Fence micro-adjustment knobs
• 4" of fence travel
• Power feeder attachment locations (power feeder not included)
• 3 speeds: 5000, 7000, 10,000
• Quick-release belt tensioner
• Poly-V belt drive
• 3/4", 1-1/4" spindles included
• Fully adjustable clear guard

ACCESSORIES INCLUDED:

• Open-end wrenches 14 x 17mm, 22 x 24mm
• Spindle wrench 50mm
• Hex wrenches 3, 6mm
• Combo screwdriver #1
• Starting pin
• Featherboards for table and fence
