SPECIFICATIONS:

• Motor: 2 HP, 120V/240V (prewired 240V), single-phase, 18A/9A
• Maximum cutter height: 2-1/2"
• Maximum cutter diameter: 5"
• Spindle diameters: 1/2", 3/4"
• Spindle length: 5"
• Spindle travel: 3"
• Spindle capacity under nut: 2", 2-3/8"
• Spindle speeds: 7000, 10,000 RPM
• Spindle openings: 1-1/4", 3-1/2", 5"
• Table counterbore: 5" dia. x 0.60" deep
• Table size: 24" x 21"
• Footprint: 19-1/4" x 18-1/2"
• Approximate shipping weight: 293 lbs.

FEATURES:

• Two-year warranty!!
• Large precision-ground cast-iron table
• Spindles: 1/2" and 3/4" (included)
• Powder-coated finish
• Mirco-adjustable split fence system
• Heavy-duty miter gauge
• Motor reversing switch
• 3" Dust port
• Split-fence has independent micro-adjustment feature
• Cast-Iron table and handwheel
• Lockable reversing switch
